Quartz Crystal TSQ-HC49SMD

Quartz Crystal TSQ-HC49SMDQuartz Crystal TSQ-HC49SMD
Following is a Quartz Crystal TSQ-HC49SMD specifications and features.

Quartz Crystal TSQ-HC49SMD Features

  1. Low cost, Good aging
  2. Wide frequency range
  3. Tight Tolerance and Stability
  4. Pb-free & RoHS Compliance

    5. Quartz Crystal TSQ-HC49SMD Applications

  5. Ideally suited for Set-Top Box/ Multimedia. Modems, clock/VCXO multiplier, network adapter cards and remote contol devices.

Quartz Crystal TSQ-HC49SMD Parameters download PDF files View PDF

Quartz Crystal TSQ-HC49SMD Specifications
Holder Type HC-49S SMD 2pad
Frequency Range 3.200MHz – 100.000MHz
Operating Temperature Range --20℃ - +70℃ / -40℃ - +85℃ or custom-designed
Storage Temperature Range -40℃ - +85℃/-55℃ - +125℃
Drive Level 100uW typical
Load Capacitance 8pF-32pF or Series
Frequency Tolerance ±10ppm to ±30ppm or custom-designed
Frequency Stability ±50ppm or custom-designed
Shunt Capacitance 7.0pF Max
Insulation Resistance 500MΩmin.at DC 100V
Aging First Year ±3ppm/ year Maximum
