TS13HR vs. TS13CZ: Choosing the Right SMD Capacitor

Suntan Technology Company Limited
--- All Kinds of Capacitors

Selecting the right capacitor for your electronic design is crucial, as it directly impacts the performance, reliability, and longevity of your devices. Suntan Technology Company Limited offers two excellent SMD Aluminum Electrolytic Capacitors—the TS13HR and TS13CZ. Both are designed to meet specific application needs, but choosing between them requires an understanding of their distinct features and benefits. In this blog, we will provide a comparative analysis of the TS13HR and TS13CZ series to help you make an informed decision.

TS13HR Series: High-Temperature Stability and Endurance

The TS13HR series is specifically engineered to perform reliably in high-temperature environments, making it an ideal choice for applications where thermal stability is critical.

🔎Key Features of TS13HR:

▪ Operating Temperature: -40°C to +125°C
▪ Capacitance Range: 6.8µF to 2200µF
▪ Voltage Rating: 10V to 450V
▪ Endurance: 4000 hours assured at 125°C
▪ Low ESR and High Ripple Current: Ensures efficient energy management
▪ Compliance: Meets IATF16949 and AEC-Q200 standards

🔎Ideal Applications for TS13HR:

1. Industrial Equipment: Designed to withstand extreme temperatures and harsh environments, making it perfect for industrial machinery, motor drives, and control systems.
2. Automotive Electronics: Offers the thermal stability required for automotive applications, such as engine control units and power management systems.
3. Power Supplies: Ensures long-term reliability and efficient performance in high-power applications.

TS13CZ Series: Optimized for High-Efficiency and Compact Designs

The TS13CZ series is tailored for applications that require high efficiency and compact size, making it a versatile choice for modern electronic devices.

🔎Key Features of TS13CZ:

▪ Capacitance Range: 10µF to 1000µF
▪ Voltage Rating: 10V to 100V
▪ Low ESR and High Ripple Current: Supports stable operation and efficient energy conversion
▪ Compact Design: Optimized for space-constrained applications
▪ Extended Lifespan: Reliable performance over a long period

🔎Ideal Applications for TS13CZ:

1. Consumer Electronics: Ideal for devices such as smartphones, tablets, and laptops, where space is limited, and efficiency is key.
2. Audio-Visual Equipment: Enhances performance in audio-visual systems, including amplifiers, speakers, and televisions, by ensuring smooth power delivery.
3. Portable Devices: Suitable for compact and portable electronics like smartwatches and fitness trackers, where every millimeter of space counts.

Comparative Analysis

Temperature Tolerance:

▪TS13HR: Operates up to 125°C, making it the better choice for high-temperature applications.
▪TS13CZ: Operates up to 105°C, which is sufficient for most consumer electronics but may not be ideal for more demanding industrial or automotive environments.

🔎Capacitance and Voltage Range:

▪TS13HR: Offers a broader range of capacitance and voltage ratings, making it versatile for various high-power applications.
▪TS13CZ: While slightly more limited in range, it is optimized for efficiency and space-saving designs in compact electronic devices.

🔎Size and Design:

▪TS13HR: Larger and designed for durability in extreme conditions.
▪TS13CZ: More compact, suitable for space-constrained designs without sacrificing performance.

🔎Compliance and Standards:

▪TS13HR: Meets stringent automotive and industrial standards (IATF16949 and AEC-Q200), ensuring it can be used in highly regulated environments.
▪TS13CZ: While not specifically mentioned, it is designed with efficiency and reliability in mind, adhering to general quality standards for consumer electronics.

Making the Right Choice

Choosing between the TS13HR and TS13CZ depends on the specific requirements of your application:
▪ If you are designing for industrial or automotive applications where high temperature and endurance are critical, TS13HR is the optimal choice.
▪ If your project involves compact consumer electronics where efficiency and size are priorities, TS13CZ would be the better option.

Both series offer outstanding reliability, low ESR, and high ripple current capabilities, ensuring that your electronic designs perform at their best.

Conclusion

Understanding the distinct characteristics and ideal applications of the TS13HR and TS13CZ series is essential for selecting the right SMD Aluminum Electrolytic Capacitor for your project. Whether you prioritize high-temperature stability or need a compact, efficient capacitor, Suntan Technology Company Limited has the solution to meet your needs.

For more detailed specifications and information, please refer to the datasheets:

🔗 TS13HR Datasheet
🔗 TS13CZ Datasheet
