275VAC Metallized Polypropylene Film Capacitor - X2 - TS08S

Metallized Polypropylene Film Capacitor - X2275VAC METALLIZED POLYPROPYLENE FILM CAPACITOR – X2
NON – INDUCTIVE, (UL940V-0) PLASTIC CASE SEALED WITH EPOXY RESIN

275VAC Metallized Polypropylene Film Capacitor - X2 Features

  1. Provides interference suppression with VDE & ENEC and UL safety approvals.
  2. Used in across-the-line,interference suppression circuit.

Important Notice : Marking change on TS08S series - X2 safety capacitor

Since 2019 July, TS08S series will be discontinued, and we recommend you using our X2 310VAC TS08H series to replace. Approvals: UL, cUL, VDE, ENEC. So accordingly our products will have new marking on the body. Please get noticed and thanks for your understanding.

275VAC Metallized Polypropylene Film Capacitor - X2 Parameters download PDF files View PDF

New 275VAC Metallized Polypropylene Film Capacitor - X2 Parameters download PDF files View PDF

275VAC Metallized Polypropylene Film Capacitor - X2 Specifications
Voltage Rating 275VAC
Capacitance Range 0.001 – 2.2uF
Capacitance Tolerance ±10% std.
Operating Temperature -40°C to 110°C
Testing Voltage 4.3UR DC /5s
Dissipation Factor tgδ≤0.0010 1KHz
Insulation Resistance CR≤0.33μF, I.R≥15,000MΩ
CR>0.33μF, I.R≥6,000S(MΩ/μF)
